Smoke and Fog Generators
G-fog
G-fog is a professional gas-oil fog machine designed to produce dense, stable white fog with smooth output adjustment. The device operates on proprietary X1 oil-based fluid and CO₂ or N₂ gas, and supports both local control and DMX/RDM.
Description
G-fog is a professional gas-oil type fog generator intended for concert venues, theaters, television studios, show productions, and permanent installations where dense, uniform, and visually clean white fog is required. The basic architecture of this class of devices ensures stable operation at all power levels and continuous fog generation when fluid and gas are available.
The device uses proprietary X1 oil-based fluid and CO₂ or N₂ gas, allowing it to produce fine white fog with smooth output adjustment from 0 to 100%. At maximum output, the generator produces up to 200 m³/min of fog while maintaining stable effect quality across the full adjustment range.
For convenient integration into a show system, g-fog supports local control through a built-in interface, as well as control via DMX512/RDM. The design includes an automatic purge system for the heating module, which reduces the risk of residue buildup and clogging, increasing reliability and ease of operation during intensive use.
Advantages G-fog:
- G-fog is a professional gas-oil type fog generator intended for concert venues, theaters, television studios, show productions, and permanent installations where dense, uniform, and visually clean white fog is required. The basic architecture of this class of devices ensures stable operation at all power levels and continuous fog generation when fluid and gas are available.
- The device uses proprietary X1 oil-based fluid and CO₂ or N₂ gas, allowing it to produce fine white fog with smooth output adjustment from 0 to 100%. At maximum output, the generator produces up to 200 m³/min of fog while maintaining stable effect quality across the full adjustment range.
- For convenient integration into a show system, g-fog supports local control through a built-in interface, as well as control via DMX512/RDM. The design includes an automatic purge system for the heating module, which reduces the risk of residue buildup and clogging, increasing reliability and ease of operation during intensive use.
Main Features:
| Maximum output | 200 m³/min |
| Fog output adjustment | 0–100% |
| Fluid consumption | 2 l/h at 1.0 bar |
| Fluid type | proprietary X1 oil-based fluid |
| Gas type | CO₂ or N₂ |
| Gas consumption | 2.68 kg/h at 1.0 bar |
| Control | local interface, DMX512, RDM |
| Control connectors | XLR-5, XLR-3 |
| Tank capacity | 2.5 l |
| Automatic purge system | yes |
| Fog color | white |
| Particle size | 0.5–0.7 μm |
| Warm-up time | up to 8 minutes |
| Power supply | 200–230 VAC, 50/60 Hz, single phase |
| Power consumption | 1500 W |
| Dimensions | 610 × 180 × 300 mm |
| Weight | 16.62 kg |
